Introduction

Specification

No.

item

Q336D

1

productivity

0.6-1.2Ton/hour

2

feeding amount

200kg

3

maximum weight of single piece

10kg

4

diameter of end disk

Φ 650mm

5

effective volume

0.15CBM

6

abrasive flow rate

120kg/min

7

ventilation capacity

2000CBM

8

power consumption

11.6KW

9

Blast wheel driving type

Motor direct, no belt

10

outline dimesion

1660*1880*2590mm

11

Crawler material

rubber



One circle time of shot blasting process

Workpiece material

Process time

Casting iron

310min

Casting steel

1025min

Forge piece

815min

1-1
